RS-232 ONLY Interface Enter/Exit Programming Mode
Product Reference Guide
23
Parity
This feature specifies parity required for sending and receiving data. A parity
check bit is the most significant bit of each ASCII coded character. Select the
parity type according to host device requirements.
• Select None when no parity bit is
required.
• Select Odd parity and the parity bit value is
set to 0 or 1, based on data, to
ensure that an odd number of 1 bits are contained in the coded character.
• Select Even parity and the pari
ty bit value is set to 0 or 1, based on data, to
ensure that an even number of 1 bits are contained in the coded character.
DEFAULT
Parity = None
Parity = Even
Parity = Odd
$CR2PA00
$CR2PA01
$CR2PA02
