Reading Parameters
Product Reference Guide
239
RGB Good Read Holding Time
This parameter specifies the time it will take for the RGB good read to change
the status from an Off state to Brightness state.
The delay can be set within a range of zero (0) to 255 milliseconds (25.5 sec-
onds) in 100ms increments. A setting of zero specifies no delay.
To set the time:
1. Determine the desired setting in milliseconds.
2. Divide the desired setting by 100 (setting is in 100ms increments). Pad the
re
sult with leading zeroes to yield two digits. For example: 0 = 00, 5 = 05,
20 = 20, etc.
3. Scan the ENTER/EXIT PROGRAMMING MODE bar code to enter Program-
ming Mode.
4. Go to
page 78
and scan the bar code: SELECT RGB GOOD READ HOLDING
TIME.
5. Scan the appropriate two digits from the keypad in
Appendix D, Keypad
, that
represent the duration which was determined in the steps above.
NOTE
If you make a mistake before the last character, scan the CANCEL bar code
to abor
t and not save the entry string. You can then start again at the
beginning.
6. Scan the ENTER/EXIT PROGRAMMING MODE bar code to exit.
This completes the procedure. See the following table for examples of how to
set this fe
ature.
Table 16. RGB Good Read Holding Time Examples
STEP ACTION EXAMPLES
1 Desired Setting
100ms 200ms 1,000ms (1 sec.) 5,000ms (5 secs.)
2 Divide by 100
01 02 10 50
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SELECT RGB GOOD READ HOLDING TIME
5
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘1’ ‘0’ and ‘2’ ‘1’ and ‘0’ ‘5’ and ‘0’
6 Scan ENTER/EXIT PROGRAMMING MODE
