Enter/Exit Programming Mode Code 11

172 Heron™ HD3130

Code 11 Interdigit Ratio — cont.

$CC1IR06

Code 11 Interdigit Ratio = 6

$CC1IR07

Code 11 Interdigit Ratio = 7

$CC1IR08

Code 11 Interdigit Ratio = 8

$CC1IR09

Code 11 Interdigit Ratio = 9

$CC1IR0A

Code 11 Interdigit Ratio = 10
