Enter/Exit Programming Mode Code 93

196 Heron™ HD3130

Fixed Length:

For fixed length decoding, two different lengths may be set.

DEFAULT

Code 93 Length Control = Variable Length

Code 93 = Fixed Length

$CC9LC00

$CC9LC01
