Hardware Description 57
Table 4-1 contains the System Status LED definitions.
PowerConnect M8024 LEDs
The front panel contains light emitting diodes
(LEDs) that provide information about the status of the
PowerConnect M8024 unit.
Figure 4-7. Front Panel LEDs
Table 4-1. PowerConnect M6348 Power and Status LED Definitions
LED Color Definition
Green Power is being supplied to the
PowerConnect M6348 module
Off The PowerConnect M6348 does not have
power.
Blue The switch is the stack master.
Off The switch is not the stack master.
Amber A fault has occurred, or the switch is
booting.
System Status LED
System Power
