Connect the Front End for a Dual-Controller Storage Center
Dell Compellent 11 3
3 Connectfaultdomain2(showninblue)toswitch1.
 PrimaryportP2:ControllerB,slot4,port2→Switch1
 ReservedportR2:ControllerA,slot4,port2→Switch1
4 Connectfaultdomain3(showningreen)toswitch2.
 PrimaryportP3:ControllerA,slot4,port1→Switch2
 ReservedportR3:ControllerB,slot4,port1→Switch2
5 Connectfaultdomain4(showninpurple)toswitch2.
 PrimaryportP4:ControllerB,slot3,port2→Switch2
 ReservedportR4:ControllerA,slot3,port2→Switch2
Figure 97. Dual-controller with Dual-Network iSCSI in Legacy Mode
Ethernet Switch 1
iSCSI Network 1
Server
Ethernet Switch 2
iSCSI Network 2
Controller B
Controller A
R3 P4R4 P3P1 P2R1 R2
4 3 21
4 3 21
12
12
21
21
