Label the Front-End Cables
Dell Compellent 11 7
2 ApplycablelabelstobothendsofeachiSCSIcablethatconnectsacontrollertoafront‐
endswitch.
a Preparetwolabelsbywritingthecontrollernumber,slot,andportthatthecableis
connectedto.
b Neartheconnector,alignthelabelperpendiculartothecableandaffixitstarting
withthetopedgeofthelabel.
Figure 101. Align Cable Label
c Wrapthelabelaroundthecableuntilitfullyencirclesthecable.Thebottomofeach
pre‐madelabelisclearsothatitdoesnotobscurethetext.
Figure 102. Wrap Cable Label
d Applyamatchinglabeltotheotherendofthecable.
