SC8000 Controller
Dell Compellent 9
Setup Menu
TheSetupmenudisplaysuser‐configurabledefaultsforiDRAC,LCDerrormessages,and
theHomescreen.
View Menu
TheSetupmenudisplaysiDRAC,asset,power,andtemperatureinformation.
Note: WhenyouselectanoptionintheSetupmenu,youmustconfirmtheoption
beforeproceedingtothenextaction.
Option Description
iDRAC SelectDHCPorStaticIPtoconfigurethenetworkmode.IfStaticIPisselected,the
availablefieldsareIP,Subnet(Sub),andGateway(Gtw).SelectSetupDNSto
enableDNSandtoviewdomainaddresses.TwoseparateDNSentriesareavailable.
Seterror SelectSELtodisplayLCDerrormessages
inaformthatmatchesthedescriptionin
theSystemEventLog.ThisisusefulwhentryingtomatchanLCDmessagewitha
SystemEventLogentry.
SelectSimpletodisplayLCDerrormessagesinasimplifieduser‐friendly
description.SeeSC8000ServiceGuideforalistofmessagesin
thisformat.
Sethome SelectthedefaultinformationdisplayontheLCDHomescreen.SeeViewMenuto
seetheoptionsandoptionitemsthatcanbesetasthedefaultontheHomescreen.
Note: WhenyouselectanoptionintheViewmenu,youmustconfirmtheoption
beforeproceedingtothenextaction.
Option Description
iDRACIP DisplaystheIPv4orIPv6addressesfortheiDRAC7.AddressesincludeDNS
(PrimaryandSecondary),Gateway,IP,andSubnet(IPv6doesnothaveSubnet).
MAC DisplaystheMACaddressesforiDRAC,iSCSI,orNetworkdevices.
Name DisplaysthenameoftheHost,Model,orUserStringforthecontroller.
Number DisplaystheAssettagortheServiceTagforthecontroller.
Power DisplaysthepoweroutputofthecontrollerinBTU/hrorWatts.Thedisplayformat
canbeconfiguredintheSethomesubmenuoftheSetupmenu.
Temperature DisplaysthetemperatureofthecontrollerinCelsiusorFahrenheit.Thedisplay
formatcanbe
configuredintheSethomesubmenuoftheSetupmenu.
