Appendix A Adding or Removing an Enclosure
180 Storage Center SC8000 Controller Deployment Guide
Figure 113. Disconnect Controllers (A side)
Enclosure 1
Enclosure 2
Controller A
Controller B
Disconnect
Controllers,
A-side
Move Cable
to Enclosure
2, port C
ABC
4321
4321
ABC
ABC ABC
