Connect SC280 Enclosures
Dell Compellent 83
Path Connections
IPC (Optional)CreateIPCconnectionsbetweenbothcontrollersonports2and4of
eachSASIOcard.
SC280 Enclosures
Chain1:ASide 1 ControllerA:slot2,port1→Enclosure1:leftEMM,portC.
2Enclosure1leftEMM,portB→Enclosure2:leftEMM,portA.
3 FinishwithEnclosure 2:leftEMM,portC→ControllerB:slot2,port3.
Chain1:BSide 1 ControllerB:slot3,
port1→Enclosure1:rightEMM,portC.
2Enclosure1rightEMM,portA→Enclosure2:rightEMM,portB.
3 FinishwithEnclosure 2:rightEMM,portC→ControllerA:slot3,port3.
SC200/220 Enclosures
Chain2:ASide 1 ControllerA:slot2,port3→Enclosure3:topEMM,portA.
2Enclosure3topEMM,portB→Enclosure4:topEMM,portA.
3 FinishwithEnclosure 4:topEMM,portB→ControllerB:slot2,port1.
Chain2:BSide 1 ControllerA:slot3,
port1→Enclosure4:bottomEMM,portB.
2Enclosure4bottomEMM,portA→Enclosure3:bottomEMM,portB.
3 FinishwithEnclosure 3:bottomEMM,portA→ControllerB:slot3,port3.
