Dodge Neon 2001 - Page 384

C206 - LT. GRAY (I/P SIDE)
CAV CIRCUIT
1 F15 18DG/WT (SIDE AIRBAG)
2 D25 18VT/YL (SIDE AIRBAG)
3 Z6 18BK/PK (SIDE AIRBAG)
4 Z8 16BK/VT
5 A120 16RD/LG
6-
C208 - YELLOW (SIDE AIRBAG JUMPER SIDE)
CAV CIRCUIT
1-
2-
3 R32 18YL/OR
4 R34 18OR/YL
C208 - YELLOW 4 WAY(SEAT SIDE)
CAV CIRCUIT
1-
2-
3 R32 18OR
4 R34 18WT
C209 - YELLOW (SIDE AIRBAG JUMPER SIDE)
CAV CIRCUIT
1-
2-
3 R31 18YL/OR
4 R33 18OR/YL
C209 - YELLOW (SEAT SIDE)
CAV CIRCUIT
1-
2-
3 R31 18OR
4 R33 18WT
PL 8W-80 CONNECTOR PINOUTS 8Wa - 80 - 19
ProCarManuals.com
2001 NEON
