DESCRIPTION - RHD
This section provides illustrations identifying the
general location of the splices in this vehicle. A splice
index is provided. Use the wiring diagrams in each
section for splice number identification. Refer to the
index for proper splice number. For splices that are
not shown in the figures N/S appears in the Fig. col-
umn.
Splice Location Fig.
S102 Near Right Headlamp 19
S103 Near Inlines C104 and C103 T/O 20
S104 In Data Link Connector 20
S105 Near Data Link Connector T/O 20
S106 Inside Power Distribution Center 18
S107 Near Brake Fluid Level Switch T/O 17
S108 Near Inline C112 (1.6L) T/O 18
S109 Near Power Distribution Center 18
S110 Near Left Repeater Lamp 17
S111 Near Right Headlamp 19
S112 Near Brake Fluid Level Switch T/O 17
S113 Near Throttle Position Sensor T/O 17
S114 Near Throttle Position Sensor T/O 17
S115 Near Right Front Park/Turn Signal Lamp 18
S117 Near A/C Compressor Clutch T/O 19
S118 Near Left Repeater Lamp 17, 18
S119 Near Radiator Fan Motor T/O 17
S120 Near Siren T/O 17
S121 (1.6L) Near Ground Point G108/G109 T/O N/S
S121 (2.0L) Near Powertrain Control Module-C1 T/O 21
S122 (1.6L) Near Engine Coolant Temperature Sensor T/O N/S
S122 (2.0L) Near Noise Suppressor T/O 22
S123 Near vehicle Speed Sensor T/O 22
S124 Near Powertrain Control Module-C1 T/O 21
S125 Near Starter Motor T/O 21
S128 Near Engine Oil Pressure Switch T/O 22
S129 (2.0L) Near Inline C102 T/O 22
S130 Near Ignition Coil T/O 22
S131 Near Right Headlamp 19
S133 Near Underhood Lamp T/O N/S
S134 Near Underhood Lamp T/O N/S
S135 Near Crankshaft Position Sensor T/O N/S
S136 Near Inline C101 T/O 18, 22
S137 Near Throttle Position Sensor T/O 17
S138 Near Transmission Range Sensor T/O N/S
S139 Near Transmission Range Sensor T/O N/S
S141 Near High Note Horn T/O N/S
S142 Near High Note Horn T/O N/S
8Wa - 95 - 18 8W-95 SPLICE LOCATIONS PL
