WIND DEFLECTOR
REMOVAL
(1) Open sunroof to full open position.
(2) Pull one end of wind deflector flap out of the
wind deflector (Fig. 1).
(3) Release corner piece locking tab and separate
corner piece from wind deflector beam.
(4) Rotate corner piece outboard to release tab
from roof flange.
(5) Rotate corner piece to a vertical position and
pull it up through hole in the sunshade guide.
(6) Repeat for other corner piece.
INSTALLATION
(1) Hold corner piece vertically and push tab down
through hole in the sunshade guide.
(2) Rotate corner piece inward and place tab under
roof flange.
(3) Connect corner piece to wind deflector.
(4) Install wind deflector flap into wind deflector.
(5) Repeat for other corner piece.
