(70) Install and torque input and output speed
sensors to case to 27 N·m (20 ft. lbs.).
INSTALLATION
(1) Install transaxle assembly to engine. Install
and torque transaxle-to-engine bolts to 108 N·m (80
ft. lbs.).
(2) Raise engine/transaxle assembly into position
with screw jack and wood block.
(3) Install and torque transaxle upper mount-to-
rail through-bolt to 118 N·m (87 ft. lbs.).
(4) Remove transmission jack and screw jack sup-
ports.
(5) Install torque converter-to-drive plate bolts and
torque to 88 N·m (65 ft. lbs.).
(6) Install converter dust shield.
(7) Install and torque right lateral bending brace-
to-transaxle bolt to 81 N·m (60 ft. lbs.).
(8) Install starter motor assembly.
(9) Install left lateral bending brace. Torque brace-
to-transaxle case bolts to 108 N·m (80 ft. lbs.). Torque
brace-to-engine bedplate bolt to 54 N·m (40 ft. lbs.).
Torque brace-to-intake manifold bolt to 28 N·m (200
in. lbs.).
(10) Install structural collar.
(11) Install power steering oil cooler.
(12) Install halfshafts.
(13) Lower vehicle.
(14) Install gearshift cable to mount. Secure cable
end to manual valve lever.
(15) Install solenoid/pressure switch assembly con-
nector.
(16) Connect input speed sensor connector.
(17) Connect output speed sensor connector.
(18) Install cooler lines with service splice kit.
Refer to instructions provided with kit.
(19) Install air cleaner/throttle body assembly.
(20) Install battery tray.
(21) Install battery and hold down.
(22) Connect battery cables.
(23) Fill transaxle with suitable amount of flui-
d.(Refer to 21 - TRANSMISSION/TRANSAXLE/AU-
TOMATIC - 41TE/FLUID - STANDARD
PROCEDURE).
21s - 118 41TE AUTOMATIC TRANSAXLE PL
41TE AUTOMATIC TRANSAXLE (Continued)
