8W-90 CONNECTOR/GROUND LOCATIONS
TABLE OF CONTENTS
page page
CONNECTOR/GROUND LOCATIONS
DESCRIPTION - LHD.......................1
DESCRIPTION - RHD......................22
CONNECTOR/GROUND
LOCATIONS
DESCRIPTION - LHD
This section provides illustrations identifying con-
nector and ground locations in the vehicle. A connec-
tor and ground index is provided. Use the wiring
diagrams in each section for connector and ground
identification. Refer to the index for the proper figure
number. For items that are not shown in this section
N/S is placed in the Fig. column.
Connector Name/Number Color Location Fig.
A/C Compressor Clutch BK Right Front of Engine Compartment 1, 3
A/C Cycling Switch BK Right Center of Instrument Panel N/S
A/C-Heater Blower Motor BK Right Side of Instrument Panel N/S
A/C-Heater Control GY Center of Instrument Panel 8
A/C High Pressure Switch BK Front Center of Engine Compartment 1, 2, 3
A/C Low Pressure Switch BK Right Rear of Engine Compartment 1, 3
Accelerator Pedal Position Sensor
(1.6L)
BK Left Front Kick Panel N/S
Airbag Control Module YL Center Console Behind Shift Lever 11
Antenna BK Center of Instrument Panel 7, 8
Back-Up Lamp Switch (MTX) GY Left Front of Engine Compartment 2
Battery - Left Side of Engine Compartment 6
Blower Motor Resistor Block BK In Plenum N/S
Brake Fluid Level Switch BK Near Left Front Strut Tower N/S
Brake Lamp Switch - Top of Brake Pedal 2
Brake Transmission Shift Interlock
Solenoid
WT Left Side of Instrument Panel 2
C101 BK Left Front of Engine Compartment 2, 4, 5
C102 LT GY Left Front of Engine Compartment 2, 4, 5
C103 BK Left Side of Instrument Panel 2, 7, 9
C104 GY Left Side of Instrument Panel 2, 7, 9,
C105 BK At Left Kick Panel Area 2, 12
C106 BK Left Rear of Engine Compartment 2
C107 BK Near Left Front Strut Tower 2
C108 BK Left Front of Engine Compartment N/S
C109 BK Lower Right Front Facia 1
C112 (1.6L) BK Left Front Engine Compartment 2
C201 GY Right Side of Instrument Panel 7, 17
PL 8W-90 CONNECTOR/GROUND LOCATIONS 8Wa - 90 - 1
