Connector Name/Number Color Location Fig.
C202 LT GN Right Upper Instrument Panel 7, 8
C203 LT GY Right Upper Instrument Panel 7, 8
C204 RD Left Upper Instrument Panel 7, 9, 10
C205 GY Left Lower Instrument Panel 7, 9, 16
C206 LT GY Rear of Center Console 11
C208 YL Below Left Front Seat 11
C209 YL Below Left Front Seat 11
C210 (Built-Up-Export) BK Left Side of Passenger Compartment Near B -
Pillar
11
C301 RD Right C-Pillar 13
C302 BK Inner Left Rear Quarter Panel 13
C303 BL/BK Left B-Pillar at Rear Door 12, 18
C304 BL/BK Right B-Pillar at Rear Door 14, 18
C305 NAT Left Side of Instrument Panel 7, 9, 12
C306 BK Center of Headliner 10
Camshaft Position Sensor BK Rear of Engine N/S
Cargo Lamp BK Under Parcel Shelf 13
Center High Mounted Stop Lamp BK Decklid 19
Center Stack Lamp BK Center of Instrument Panel 8
Cigar Lighter/Power Outlet RD Center of Instrument Panel 8
Clockspring GR Rear of Steering Wheel 7
Clutch Interlock /Upstop Switch
(MTX)
BK Top of Clutch Pedal 2
Controller Antilock Brake BK Near Left Strut Tower 2, 7
Crankshaft Position Sensor BK Right Front of Engine N/S
Data Link Connector BK At Left Kick Panel Area 2
Decklid Solenoid BK On Decklid 19
Decklid Release Switch BK In Glove Box 8
Decklid Security Switch GY On Decklid 19
Diode - Front Right Side of Engine Compartment 3
Dome Lamp BK Center Roof N/S
Dome Lamp/Intrusion Sensor
(Built-Up-Export)
NAT Center Roof N/S
Driver Airbag YL Front of Steering Wheel N/S
Driver Cylinder Lock Switch BK At Driver Door 16
Driver Door Ajar Switch Left B-Pillar N/S
Driver Door Lock Motor/Ajar Switch BK At Driver Door 16
Driver Door Lock Switch BK At Driver Door 16
Driver Power Mirror GY At Driver Door 16
Driver Power Window Motor BK At Driver Door 16
Driver Power Window Switch - C1 BK At Driver Door 16
Driver Power Window Switch - C2 GY At Driver Door 16
8Wa - 90 - 2 8W-90 CONNECTOR/GROUND LOCATIONS PL
CONNECTOR/GROUND LOCATIONS (Continued)
