Connector Name/Number Color Location Fig.
Electronic Throttle Control Module
(1.6L)
- Right Front of Engine N/S
Engine Coolant Temperature Sensor BK Right Front of Engine N/S
Engine Oil Pressure Switch GN Right Rear of Engine 5
Evap Purge Solenoid BK Left Rear of Engine 2
Fuel Injector NO.1 BK Top of Engine 4
Fuel Injector NO. 2 BK Top of Engine 4
Fuel Injector NO. 3 BK Top of Engine 4
Fuel Injector NO. 4 BK Top of Engine 4
Fuel Pump Module LT GY At Fuel Tank N/S
Fuse Block Left Side of I/P 7
G102 Left Front of Engine Compartment 2
G103 Right Front of Engine Compartment 3, 4
G104 Near Engine Starter Motor N/S
G105 Near Negative Battery Terminal N/S
G106 (2.0L) Left Front of Engine Compartment N/S
G107 Right Front of Engine Compartment 3, 4
G108 Right Front of Engine Compartment N/S
G109 Right Front of Engine Compartment N/S
G201 Lower Center of Instrument Panel 8, 9
G202 Lower Center of Instrument Panel 8, 9
G203 Lower Center of Instrument Panel 8, 9
G204 Lower Center of Instrument Panel 8, 9
G301 Inner Left Rear Quarter Panel 13
G302 Inner Right Rear Quarter Panel 14
G303 Inner Left Rear Quarter Panel 13
G304 At Decklid 19
Generator BK Left Rear of Engine 5
Glove Box Lamp/Switch BK Right Side of Instrument Panel 7, 8
Headlamp Leveling Switch (Built-Up-
Export)
BK Center of Instrument Panel 8
High Note Horn BK Right Inner Fender N/S
Hood Ajar Switch BK Right Side of Engine Compartment 1
Horn Switch BK Steering Column N/S
Idle Air Control Motor (2.0L) BK On Throttle Body 2
Ignition Coil BK Top of Valve Cover 5
Ignition Switch BK Right Side of Steering Column 7
Inlet Air Temperature Sensor BK Left Front of Engine Compartment 2, 6
Input Speed Sensor (EATX) GY Lower Left of Engine Compartment 2
Instrument Cluster BK Left Upper Instrument Panel 7
Knock Sensor (1.6L) BK Left Front of Engine N/S
Knock Sensor (2.0L) BK Left Front of Engine N/S
Leak Detection Pump BK Left Rear of Vehicle 15
PL 8W-90 CONNECTOR/GROUND LOCATIONS 8Wa - 90 - 3
CONNECTOR/GROUND LOCATIONS (Continued)
