Connector Name/Number Color Location Fig.
Left Back-Up Lamp BK Left Rear Fascia 13
Left Front Door Speaker BK At Drivers Door 16
Left Front Fog Lamp BK Lower Left Facia N/S
Left Front Side Marker Lamp NAT Left Front Side Fender 1
Left Front Turn Signal Lamp
(Built-Up-Export)
NAT Left Front Facia N/S
Left Front Wheel Speed Sensor BK At Left Front Wheel Opening 2
Left Headlamp (Built-Up-Export) Left Headlamp Opening N/S
Left Headlamp (Except Built-Up-
Export)
BK Left Headlamp Opening 2
Left Instrument Panel Speaker BK Left Upper Instrument Panel 7
Left Lavalier Module (Built-Up-Export) BK Left Front of Engine Compartment N/S
Left License Lamp (Built-Up-Export) NAT Center Rear Fascia 15
Left Park/Turn Signal Lamp (Except
Built-Up-Export)
BK Lower Left Facia 2
Left Rear Door Ajar Switch Rear of Left Rear Door Opening 13
Left Rear Door Lock Motor/Ajar
Switch
BK Rear of Left Rear Door Opening 18
Left Rear Fog Lamp (Built-Up-Export) GY Left Rear Bumper N/S
Left Rear Speaker BK Left Side Package Tray 13
Left Rear Turn Signal Lamp
(Built-Up-Export)
GY Left Rear Facia 13
Left Rear Wheel Speed Sensor BL At Left Rear Wheel Opening N/S
Left Seat Airbag Left Side of Seat N/S
Left Side Impact Airbag Control
Module
Left Side of Passenger Compartment 12
Left Side Repeater Lamp (Built-Up-
Export)
BK Behind Left Wheel Well 1
Left Tail/Stop Lamp (Built-Up-Export) BK Left Rear of Vehicle 13
Left Tail/Stop/Turn Signal Lamp
(Except Built-Up-Export)
BK Left Rear of Vehicle N/S
Left Visor/Vanity Lamp BK Left Header Panel 10
License Lamp (Except Built-Up-
Export)
NAT Lower Center of Rear Fascia N/S
Low Note Horn BK Right Front Wheel Opening 1
Manifold Absolute Pressure Sensor Left Front of Engine N/S
Manning Tuning Valve Solenoid (RT) BK Left Front Engine N/S
Map/Reading Lamps BK Front of Headliner 10
Multi-Function Switch GY Left Side of Instrument Panel 7
Negative Battery Terminal Left Side of Engine Compartment 6
Output Speed Sensor (EATX) Left Lower Front of Engine Compartment 2
Oxygen Sensor 1/1 Upstream GY Right Rear of Engine 5
Oxygen Sensor 1/2 Downstream
(2.0L)
BK Right Rear of Engine 2, 5
