Dodge Neon 2001 - MODULAR CLUTCH; DESCRIPTION; REMOVAL

(11) Install the ABS module/purge solenoid, PDC,
and air cleaner.
(12) Depress and release the clutch pedal a mini-
mum of ten (10) times to allow any residual air in
the system to be vented to the reservoir.
(13) Connect the negative battery cable.
(14) Verify correct clutch operation.
MODULAR CLUTCH
DESCRIPTION
The modular clutch assembly (Fig. 19) is serviced
only as an assembly.
REMOVAL
(1) Raise hood.
(2) Disconnect and isolate both battery cables,
remove battery hold down clamp and bolt, and
remove battery.
(3) Remove air cleaner/throttle body assy. (Fig. 20)
as follows:
(a) Disconnect proportional purge solenoid (PPS)
and crankcase vent hose from throttle body.
(b) Disconnect the Throttle Position Sensor
(TPS) and Idle Air Control (IAC) connectors.
(c) Disconnect throttle body air duct at intake
manifold.
(d) Remove mounting bolt and nut (Fig. 20) and
partially remove air cleaner assembly.
(e)
Disconnect accelerator and speed control (if
equipped) cables after the assy. is removed from
position. Remove air cleaner assembly from vehicle.
(4) Remove battery tray from bracket.
(5) Disconnect ground cable at battery tray
bracket.
(6) Disconnect back-up lamp switch connector.
(7) Using Tool 6638A, disconnect clutch hydraulic
quick-connect (Fig. 21) (Fig. 22).
Fig. 19 Modular Clutch Assembly
1 - MODULAR CLUTCH ASSEMBLY
Fig. 20 Air Cleaner Assembly Removal/Installation
1 - AIR CLEANER ASSY.
2 - THROTTLE BODY DUCT
Fig. 21 Slave Cylinder and Hydraulic Supply Tube
1 - SLAVE CYLINDER
2 - HYDRAULIC TUBE
PL CLUTCH 6s - 11
MASTER CYLINDER (Continued)
