8W-95 SPLICE LOCATIONS
TABLE OF CONTENTS
page page
SPLICE LOCATIONS
DESCRIPTION - LHD.......................1
DESCRIPTION - RHD......................18
SPLICE LOCATIONS
DESCRIPTION - LHD
This section provides illustrations identifying the
general location of the splices in this vehicle. A splice
index is provided. Use the wiring diagrams in each
section for splice number identification. Refer to the
index for proper splice number. For splices that are
not shown in the figures N/S appears in the Fig. col-
umn.
Splice Location Fig.
S102 Near Right Headlamp 3
S103 Near Inline C104 T/O 2
S104 Near Data Link Connector T/O 2
S105 Near Inline C105 T/O 2
S106 Inside Power Distribution Center 2
S107 Near Evap Purge Solenoid T/O 2
S108 Near A/C Low Pressure Switch T/O 1
S109 Near Power Distribution Center 2
S110 Near Left Front Side Marker Lamp 1
S111 Near Right Headlamp 3
S112 Near Power Distribution Center 2
S113 Near Throttle Position Sensor T/O 2
S114 Near Throttle Position Sensor T/O 2
S115 Near Right Front Turn Signal Lamp N/S
S117 Near A/C Compressor Clutch T/O 3
S118 Near Powertrain Control Module - C2 2
S119 Near Radiator Fan Motor T/O 2
S120 (Built-Up-Export) Near Siren T/O 1
S121 (1.6L) Near Ground Point G108/G109 T/O N/S
S121 (2.0L) Near Powertrain Control Module-C1 T/O 4
S122 (1.6L) Near Engine Coolant Temperature Sensor T/O N/S
S122 (2.0L) Near Noise Suppressor T/O 5
S123 Near Vehicle Speed Sensor T/O 5
S124 Near Powertrain Control Module - C1 T/O 4
S125 Near Starter Motor T/O 4
S128 Near Engine Oil Pressure Switch T/O 5
S129 (2.0L) Near Inline C102 T/O 5
S130 Near Ignition Coil T/O 5
S131 Near Right Headlamp 3
PL 8W-95 SPLICE LOCATIONS 8Wa - 95 - 1
