Splice Location Fig.
S143 Near Powertrain Control Module-C2 N/S
S144 Near Transmission Control Module 17
S145 Near Transmission Control Module T/O 17
S146 Near Powertrain Control Module-C2 T/O N/S
S147 Near Left Park/Turn Signal Lamp 18
S148 Near A/C High Pressure Switch T/O 19
S149 Near Manifold Tuning Valve Solenoid T/O N/S
S201 Near Right Instrument Panel Speaker T/O 23
S202 Near Remote Keyless Entry Module T/O 23
S203 Near Remote Keyless Entry Module T/O 23
S204 Near Inline C202 T/O 23
S205 Near Remote Keyless Entry Module T/O 23
S206 Near Remote Keyless Entry Module T/O 23
S207 Near Instrument Cluster T/O 23
S208 Near Instrument Cluster T/O 23
S209 Near Brake Transmission Shift Interlock Solenoid N/S
S210 Near Brake Transmission Shift Interlock Solenoid N/S
S211 Near Inline C205 T/O N/S
S212 Near Instrument Cluster T/O 23
S213 Near Instrument Cluster T/O N/S
S214 Near Instrument Cluster T/O 23
S215 Near Fuse Block T/O 23
S216 Near Instrument Cluster T/O 23
S217 Near Fuse Block T/O 23
S218 Near Fuse Block T/O 23
S219 Near Fuse Block T/O 23
S220 Near Fuse Block T/O 23
S221 Near Instrument Cluster T/O 23
S222 Near Fuse Block T/O 23
S223 Near Fuse Block T/O N/S
S224 Near Fuse Block T/O 23
S225 Near Instrument Cluster T/O 23
S226 Near Inline C205 T/O 23
S227 Near Inline C103/C104/C305 23
S229 Near Airbag Control Module T/O N/S
S230 Near Transmission Range Indicator Illumination (PRNDL) 25
S231 Near Sentry Key Immobilizer Module T/O 23
S232 Near Sentry Key Immobilizer Module T/O 23
S233 Near Brake Transmission Interlock Solenoid N/S
S234 Near Brake Transmission Interlock Solenoid N/S
S235 Near Inline C206 T/O 25
S236 Near Inline C206 T/O 25
PL 8W-95 SPLICE LOCATIONS 8Wa - 95 - 19
SPLICE LOCATIONS (Continued)
