C304 - BLACK (REAR DOOR SIDE)
CAV CIRCUIT
1-
2 M9 18LB/OR
3 P33 18OR/BK (POWER LOCKS)
4-
5 P36 18PK/VT (POWER LOCKS)
6 Z1 20BK
7-
C305 - NATURAL (UNIBODY SIDE)
CAV CIRCUIT
1 L38 16BR/WT (BUILT-UP-EXPORT)
2 G71 20VT/YL (POWER LOCKS)
3 G10 20LG/RD
4 L7 20BK/YL
5 L62 18BR/RD
6 L63 18DG/RD
7 X51 18BR/YL
8 X52 18DB/WT
9 L50 20WT/TN
10 X5 20WT/RD (BUILT-UP-EXPORT)
11 G120 18WT/DB (BUILT-UP-EXPORT)
12 G4 18DB
13 M2 18YL
14 M9 20LB/OR
15 X57 18BR/LB
16 X58 18DB/OR
17 F12 18DB/WT (EXCEPT BUILT-UP-EX-
PORT)
18 -
19 P33 18OR/BK (POWER LOCKS)
20 -
21 Q2 14LG/BK
22 -
23 P36 18PK/VT (POWER LOCKS)
24 C15 12BK/WT
25 -
