SUNROOF VENT SWITCH-3WAY
CAV CIRCUIT FUNCTION
1 Z3 18BK/VT GROUND
2 Q46 20OR SUNROOF VENT SWITCH
3- -
THROTTLE POSITION SENSOR - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K4 20BK/LB SENSOR GROUND
2 K22 20OR/DB THROTTLE POSITION SENSOR SIGNAL
3 K6 18VT/WT 5V SUPPLY
TORQUE CONVERTER CLUTCH SOLENOID (ATX) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1- -
2 K54 18OR/BK TORQUE CONVERTER CLUTCH SOLENOID CONTROL
3 F12 18DB/WT FUSED IGNITION SWITCH OUTPUT (RUN-START)
TRACTION CONTROL SWITCH - WHITE 4 WAY
CAV CIRCUIT FUNCTION
1- -
2 B27 20RD/YL TRACTION CONTROL SWITCH SENSE
3 Z1 20BK GROUND
4 E2 22OR PANEL LAMPS DRIVER
PL 8W-80 CONNECTOR PINOUTS 8Wa - 80 - 59
