Connector Name/Number Color Location Fig.
C304 BL/BK Right B-Pillar at Rear Door 32, 34, 38
C305 NAT Left Side of Instrument Panel 28, 29, 32
C306 BK Center of Headliner 30
Camshaft Position Sensor BK Rear of Engine N/S
Cargo Lamp BK Under Parcel Shelf 33
Center High Mounted Stop Lamp BK Decklid 39
Center Stack Lamp BK Center of Instrument Panel 27
Cigar Lighter/Power Outlet RD Center of Instrument Panel 27
Clockspring GR Rear of Steering Wheel 28
Clutch Interlock /Upstop Switch
(MTX)
BK Top of Clutch Pedal 25
Controller Antilock Brake BK Near Right Strut Tower 21, 28
Crankshaft Position Sensor BK Right Front of Engine N/S
Data Link Connector BK At Right Kick Panel Area 25
Decklid Release Solenoid BK On Decklid 39
Decklid Release Switch BK In Glove Box 27, 28
Decklid Security Switch GY On Decklid 39
Diode - Front Right Side of Engine Compartment N/S
Dome Lamp/Intrusion Sensor NAT Center Roof N/S
Driver Airbag YL Front of Steering Wheel N/S
Driver Cylinder Lock Switch BK At Driver Door 37
Driver Door Ajar Switch Right B-Pillar 34
Driver Door Lock Motor/Ajar Switch BK At Driver Door 37
Driver Door Lock Switch BK At Driver Door 37
Driver Power Mirror GY At Driver Door 37
Driver Power Window Motor BK At Driver Door 37
Driver Power Window Switch - C1 BK At Driver Door 37
Driver Power Window Switch - C2 GY At Driver Door 37
Electronic Throttle Control Module
(1.6L)
- Right Front of Engine N/S
Engine Coolant Temperature Sensor BK Right Front of Engine N/S
Engine Oil Pressure Switch GN Right Rear of Engine 24
Evap Purge Solenoid BK Right Rear of Engine 21
Fuel Injector NO.1 BK Top of Engine 23
Fuel Injector NO. 2 BK Top of Engine 23
Fuel Injector NO. 3 BK Top of Engine 23
Fuel Injector NO. 4 BK Top of Engine 23
Fuel Pump Module LT GY At Fuel Tank N/S
Fuse Block Right Side of I/P N/S
G102 Left Front of Engine Compartment N/S
G103 Right Front of Engine Compartment 22, 23
G104 Near Engine Starter Motor N/S
G105 Near Negative Battery Terminal N/S
PL 8W-90 CONNECTOR/GROUND LOCATIONS 8Wa - 90 - 23
CONNECTOR/GROUND LOCATIONS (Continued)
