(e) Disconnect accelerator and speed control (if
equipped) cables after the assy. is removed from
position. Remove air cleaner assembly from vehi-
cle.
(9) Disconnect cables from the shift levers at the
transaxle (Fig. 44).
CAUTION: Pry up with equal force on both sides of
shifter cable isolator bushings to avoid damaging
cable isolator bushings.
Remove cable retaining clips and remove cables
from bracket (Fig. 44).
Fig. 41 Crossover Cable at Shifter Assembly
1 - GROMMET PLATE NUT
2 - SHIFTER
3 - CROSSOVER CABLE
4 - CLIP
Fig. 42 Selector Cable at Shifter Assembly
1 - SHIFTER
2 - CLIP
3 - SELECTOR CABLE
Fig. 43 Air Cleaner Assembly Removal/Installation
1 - AIR CLEANER ASSY.
2 - THROTTLE BODY DUCT
Fig. 44 Shift Cables at Transaxle
1 - SHIFT CABLES
2 - CLIPS
3 - BRACKET
21s - 18 A578 MANUAL TRANSMISSION PL
GEAR SHIFT CABLE (Continued)
