Dodge Neon 2001 - Page 569

OIL PUMP CLEARANCE
Description Metric Standard
Outer Gear-to-Pocket 0.045-0.141mm 0.0018-0.0056 in.
Outer Gear Side Clearance 0.020-0.046mm 0.0008-0.0018 in.
Inner Gear Side Clearance 0.020-0.046mm 0.0008-0.0018 in.
THRUST WASHERS
Description Metric Standard
Reaction Shaft Support (No. 1) 1.55-1.60 mm 0.061-0.063 in.
Rear Clutch Retainer (No. 2) 1.55-1.60 mm 0.061-0.063 in.
Output Shaft (No. 3) (Select) 1.98-2.03 mm 0.077-0.080 in
Output Shaft (No. 3) (Select) 2.15-2.22 mm 0.085-0.087 in.
Output Shaft (No. 3) (Select) 2.34-2.41 mm 0.092-0.095 in.
Front Annulus (No. 4) 2.95-3.05 mm 0.116-0.120 in.
Front Carrier (Nos. 5&6) 1.22-1.28 mm 0.0948-0.050 in.
Sun Gear-Front (No. 7) 0.85-0.91 mm 0.033-0.036 in
Sun Gear-Rear (No. 8) 0.85-0.91 mm 0.033-0.036 in.
Rear Carrier (Nos. 9&10) 1.22-1.28 mm 0.0948-0.050 in.
Rev. Drum (No. 11) 1.55-1.60 mm 0.061-0.063 in.
TORQUE SPECIFICATIONS
Description N·m Ft. Lbs. In. Lbs.
Bolt, Differential Bearing
Retainer-to-Case
34 — 300
Bolt, Differential
Cover-to-Case
19 — 165
Bolt, Differential Ring
Gear-to-Case
95 70 —
Bolt, Extension Housing-
to-Case
28 — 250
Bolt, Drive Plate-to-
Crankshaft
95 70 —
Bolt, Drive Plate-to-Torque
Converter
68 50 —
Bolt, Governor-to-Support 7 — 60
Bolt, Output Gear Strap 23 17 —
Bolt, Oil Pan-to-Case 19 — 165
Bolt, Oil Pump-to-Case 31 — 275
Bolt, Park Rod Support-to-
Case
28 — 250
Bolt, Reaction Support-to-
Pump Body
28 — 250
Bolt, Sprag Retainer-to-
Case
28 — 250
21s - 54 31TH AUTOMATIC TRANSAXLE PL
31TH AUTOMATIC TRANSAXLE (Continued)
