Dodge Neon 2001 - Page 711

(4) Remove 2/4 Accumulator Retaining Plate (Fig.
322).
(5) Remove 2/4 Accumulator components as shown
in (Fig. 323).
(6) Remove Valve Body to Transfer Plate screws
(Fig. 324).
(7) Invert assembly and remove Transfer Plate
(Fig. 325). Beware of loose check balls.
Fig. 322 2/4 Accumulator Retaining Plate
1 - 2–4 ACCUMULATOR RETAINING PLATE
2 - DETENT SPRING
Fig. 323 2/4 Accumulator Assembly
1 - VALVE BODY
2 - RETAINER PLATE
3 - DETENT SPRING
4 - SPRINGS
5 - SEALS
6 - PISTON
Fig. 324 Remove Valve Body to Transfer Plate
Screws
1 - SCREW (24)
2 - TRANSFER PLATE
3 - VALVE BODY
Fig. 325 Remove Transfer Plate
1 - TRANSFER PLATE
21s - 196 41TE AUTOMATIC TRANSAXLE PL
VALVE BODY (Continued)
