Duplo DC-616 Service Manual

137
Chapter 7 6 HELP Mode
7
S2-Y1540
HELP Mode : 11
1. Function
2. Operating Procedure
(1) Sensor switch check
• Status of the sensor switch ON: 0 / OFF: 1 is displayed.
(1) Sensor switch check
1. Access the HELP Mode “11”, and press the <START> key.
2. Press the UP/DOWN cursor key to switch pages.
3. Press the <STOP> key. It will return to the HELP Mode selection
screen.
Page Sensor Display
Page 1 PPS1 0: light blocked 1: light through
PPS2
0: light through 1: light blocked
PPS3
Page 2 PPS4
0: light through 1: light blockedSlit 1 hp
Slit 2 hp
Page 3 Slit 3 hp
0: light through 1: light blocked
Slit 4 hp
Slit 5 hp
Page 4 Slit 6 hp
0: light through 1: light blockedCut hp
Crease up hp
Page 5 Crease low. hp
0: light through 1: light blocked
Crease enc
Elev. dw. SW 0: ON 1: OFF
Page 6 Elev. low. SW 0: OFF 1: ON
Level sensor 0: light through 1: light blocked
Cover SW 0: OFF 1: ON
Page 7 Gutter on/off
0: light through 1: light blockedTrim waste
Perf Sensor
H11 Sens. ck.
PPS1
X
PPS2
X
PPS3
X
▼
-0
