146
Chapter 7 6 HELP Mode
S2-Y1540
HELP Mode : 27
1. Function
2. Operating Procedure
(1) Creaser upper blade motor operation test
• The proper function of the creaser upper blade motor is verifi ed.
• The proper function of the creaser upper blade home position
sensor is verifi ed.
(1) Creaser upper blade motor operation test
1. Access the HELP Mode “27”, and press the <START> key.
2. Press the UP/DOWN cursor key, and operate the motor.
UP cursor key: normal rotation
DOWN cursor key: reverse rotation
3. Verify if the sensor detects.
0: light through
1: light blocked
4. Press the <STOP> key. It will return to the HELP Mode selection
screen.
H27 Cre. mot ck
Cre. hp sen:
X
↑↓:cre. mot on
-0
