147
Chapter 7 6 HELP Mode
7
S2-Y1540
HELP Mode : 28
1. Function
2. Operating Procedure
(1) Creaser lower blade motor operation test
• The proper function of the creaser lower blade motor is verifi ed.
• The proper function of the creaser lower blade home position is
verifi ed.
(1) Creaser lower blade motor operation test
1. Access the HELP Mode “28”, and press the <START> key.
2. Press the UP/DOWN cursor key, and operate the motor.
UP cursor key: normal rotation
DOWN cursor key: reverse rotation
3. Check that the sensors detect properly.
0: light through
1: light blocked
4. Press the <STOP> key. It will return to the HELP Mode selection
screen.
H28 Cre. low ck.
Cre. low.sen. :
X
Cre. enc.sen. :
X
↑↓:cre. mot. on
-0
To Next Page
