148
Chapter 7 6 HELP Mode
S2-Y1540
HELP Mode : 29
1. Function
2. Operating Procedure
(1) Cutter motor operation test
• The proper function of the cutter motor is verifi ed.
(1) Cutter motor operation test
1. Access the HELP Mode “29”, and press the <START> key.
2. Press the UP/DOWN cursor key, and operate the motor.
UP cursor key: normal rotation
DOWN cursor key: reverse rotation
3. Check that the sensors detect properly.
0: light through
1: light blocked
4. Press the <STOP> key. It will return to the HELP Mode selection
screen.
H29 Cut mot ck.
Cut hp.sen. :
X
Cut enc.sen. :
X
↑↓:Cut mot. on
-0
