149
Chapter 7 6 HELP Mode
7
S2-Y1540
HELP Mode : 31
1. Function
2. Operating Procedure
(1) Slitter operation test (1~6)
• The proper function of the slitter motor is verifi ed.
(1) Slitter motor operation test
1. Access the HELP Mode “31”, and press the <START> key.
2. Select the slitter by pressing the RIGHT/LEFT cursor key.
3. Move the selected slitter by pressing the UP/DOWN cursor key.
UP cursor key: Move to the opposite side.
DOWN cursor key: Move to the control panel side.
4. Press the <STOP> key. It will return to the HELP Mode selection
screen.
H31
MSL&SLOT mot
Slit: 1 2 3 4 5 6
←→:Select
↑↓: Slit on
-0
