Ste
p
Description Command Keys
4 Specify the IP address of the VTI tunnel
local side (optional).
esr(config-vti)# ip address <ADDR/
LEN>
<ADDR/LEN> – IP address and
prefix of a subnet, defined as
AAA.BBB.CCC.DDD/EE where
each part AAA-DDD takes
values of [0..255] and EE takes
values of [1..31].
5 Define Diffie-Hellman group number
(optionally).
esr(config-ike-proposal)# dh-
group <DH-GROUP>
<DH-GROUP> – Diffie-Hellman
group number, takes values of
[1, 2, 5, 14, 15, 16, 17, 18].
Default value: 1
6 Create an IKE profile policy and switch
to its configuration mode.
esr(config)# security ike policy
<NAME>
<NAME> – IKE policy name, set
by the string of up to 31
characters.
7 Specify the authentication mode. esr(config-ike- policy)#
authentication method <METHOD>
<METHOD> – key
authentication method. May
take the following values:
xauth-psk-key – two-
factor authentication
method using a login-
password pair and
previously obtained
encryption keys.
8 Set the client mode (only for client). esr(config-ike- policy)#
authentication mode client
9 Specify the lifetime of IKE protocol
connection (optionally).
esr(config-ike- policy)# lifetime
seconds <SEC>
<SEC> – time interval, takes
values of [4..86400] seconds.
Default value: 3600
10 Bind the policy to profile. esr(config-ike-policy)# proposal
<NAME>
<NAME> – IKE protocol name,
set by the string of up to 31
characters.
11 Specify authentication key. esr(config-ike-policy)#pre-shared-
key ascii-text <TEXT>
<TEXT> – string [1..64] ASCII
characters.
12 Create an access profile. esr(config)# access profile
<NAME>
<NAME> – access profile
name, set by the string of up to
31 characters.
