ESR-Series. User manual
337
Proceed to the PE2 configuration:
PE2(config-mpls)# l2vpn
PE2(config-l2vpn)# vpls l2vpn
PE2(config-l2vpn-vpls)# bridge-group 1
PE2(config-l2vpn-vpls)# autodiscovery bgp
PE2(config-bgp)# rd 65500:100
PE2(config-bgp)# route-target export 65500:100
PE2(config-bgp)# route-target import 65500:100
PE2(config-bgp)# vpn id 2
PE2(config-bgp)# ve id 2
PE2(config-bgp)# exit
PE2(config-l2vpn-vpls)# enable
Check that PE2 is advertising the route information on RR:
PE2# sh ip bgp l2vpn vpls all neighbor 10.10.0.4 advertise-routes
Origin codes: i - IGP, e - EGP, ? - incomplete

Route Distinguisher VID VBO VBS Next hop Metric LocPrf Path
--------------------- ----- ----- ----- --------------- ---------- ----------
----------------------
65500:100 2 1 10 10.10.0.2 -- 100 i
In the l2vpn table you can see its routes as well as routes from PE1:
PE2# sh ip bgp l2vpn vpls all
Status codes: * - valid, > - best, i - internal, S - stale
Origin codes: i - IGP, e - EGP, ? - incomplete

Codes Route Distinguisher VID VBO VBS Next hop Metric LocPrf Weight Path
----- --------------------- ----- ----- ----- --------------- ---------- ---------- ------
-------------------
*> 65500:100 2 1 10 -- -- -- --
*>i 65500:100 1 1 10 10.10.0.1 -- 100 0 i
