ELTEX ESR Series User Manual

ESR-Series. User manual
36
•
•
Table 11 – Description of connectors, LEDs and controls located on ESR-3100 front panel
№ Front panel
element
Description
1 Status Current device status LED.
Alarm Alarm LED.
VPN VPN gateway operation mode LED.
Flash Activity of exchange with data storage – SD card or USB Flash.
Power Device power LED.
Master Failover mode operation LED (is not supported in the current version).
Fan Fan operation LED.
RPS Redundant power supply LED.
2 F Functional key that reboots the device and resets it to factory default configuration:
Pressing the key for less than 10 seconds reboots the device;
Pressing the key for more than 10 seconds resets the terminal to factory settings.
3 Console Console port RS-232 for local management of the device.
4 SD SD-card connector.
5 USB1 USB 3.0 port for USB device connection.
6 USB2 USB 3.0 port for USB device connection.
7 [1 .. 8] 8 ports of Gigabit Ethernet 10/100/1000BASE-T (RJ-45).
8 XG1 – XG8 Slots for 10G SFP+/1G SFP transceivers.

ELTEX ESR Series Specifications

General

Model	ESR Series
Category	Network Router
Manufacturer	ELTEX
Management	Web interface, CLI, SNMP
Operating Temperature	0°C to 40°C
Dimensions	Varies by model
Weight	Varies by model
Routing Protocols	OSPF, BGP
WAN Interfaces	Ethernet, SFP
LAN Interfaces	Ethernet, SFP
VPN Support	IPsec, L2TP, PPTP
Firewall	Stateful packet inspection, ACLs
Power over Ethernet (PoE)	Available on some models
QoS	Traffic prioritization
