Figure 21 – ESR-200, ESR-100 rear panel
Table 20 lists rear panel connectors of the router.
Table 20 – Rear panel connectors description
№ Description
1 Earth bonding point of the device.
2 Ventilation module.
ESR-100, ESR-200 side panels
The side panel layout of ESR-200, ESR-100 is depicted in Figures 22 and 23.
Figure 22 – ESR-100 and ESR-200 right side panel
Figure 23 – ESR-100 and ESR-200 left side panel
