ESR-14VF, ESR-12VF rear panel
The rear panel layout of ESR-12VF, ESR-14-VF is depicted in figure 33.
Figure 33 – ESR-12VF, ESR-14VF rear panel
Table 26 lists rear panel connectors of the router.
Table 26 – Rear panel connectors description
№ Description
1 Earth bonding point of the device.
