EPSON AcuLaser C1100 Revision B
DISASSEMBLY AND ASSEMBLY 500 PAPER CASSETTE & 500 PAPER FEEDER 484
REINSTALLATION
1. Attach ROLL ASSY FEED 500 to SHAFT FEED so that the hook on ROLL
ASSY FEED 500 is facing the right side, and fasten the hook on ROLL ASSY
FEED 500 to the groove on SHAFT FEED.
2. Attach ROLL SUPPORT 500 to SHAFT FEED, and fasten the hook on ROLL
SUPPORT 500 to the groove on SHAFT FEED.
3. Insert the right side of SHAFT FEED into the right-side bearing on HOUSING
ASSY FEED, then slide SHAFT FEED to the left, and attach together with ROLL
ASSY FEED 500 and ROLL SUPPORT 500.
4. Match the double D cut surface of BEARING SLEEVE with the left and right
bearings of HOUSING ASSY FEED, attach BEARING SLEEVE, and fasten both
sides of SHAFT FEED with the E-rings.
5. Attach COVER FEED to HOUSING ASSY FEED.
6. Fasten COVER FEED to HOUSING ASSY FEED with the 2 screws (silver,
tapping, 8 mm).
7. Attach HOUSING ASSY FEED. (p.476)
8. Attach DRIVE ASSY FEED. (p.458)
9. Attach CLUTCH ASSY FEED. (p.461)
10. Attach COVER LEFT 500. (p.453)
11. Attach 500 PAPER CASSETTE ASSY. (p.446)
C A U T I O N
When performing the following work, pay attention to the
attachment direction of ROLL ASSY FEED 500.
To Next Page
