EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Disassembly/assembly Disassembly/Reassembly Procedures 379
Confidential
DISASSEMBLY FLOWCHART
D9
Start
Start
Ink Eject Cover
(→P. 380)
A1
B1
Rear Cover (Back)
(→P. 380)
ASF Front Cover
(→P. 381)
Ink Eject Cover
(→P. 381)
Housing Right
(→P. 382)
Housing Left
(→P. 382)
ADF/SCN Unit
(→P. 383)
Housing Upper
(→P. 383)
Slide the Wasted Ink Duct
Holder (→P. 384)
Porous Pad Cap Lower
(→P. 388)
C1
B2
C2
B3
C3
B4
C4
B5
C5
B6
C6
B7
C7
B8
C8
Inksystem Unit
(→P. 385)
B9
D10
C H E C K
P O I N T
 As for the procedure indicated by , refer to 6.2.4.4
Housing (WF-C5200 Series) (2) (p. 254) in the case of
the WF-C5200 Series, and remove the parts from the
Rear Back Cover to the Housing Top.
 The procedure indicated by is applicable only in the
WF-C5700 Series/ET-8700.
D1
D2
D3
D4
D5
D6
D7
D8
Maintenance Box Detect
Sensor Assy (→P. 387)
C9
