ECI Multi Functional Weighing Controller Operating Manual
Page 106
3) Detail: Weight data is sent in detail. (Baudrate is 9600bps)The format of the data string sent is same
as follows.
Net
TAB
Tare
TAB
Gross
TAB
Date
TAB
Time
TAB
Status
CR
169.2
HT
128.5
HT
297.7
HT
12/02/2013
HT
09:52
HT
S
CR
Status
E:Error
Z:Absolute Zero
S:Stagnancy
- :This symbol appears when non of the abovementioned conditions occur.
4) Stability:Net weight information is sent 10 times per second when stability is observed. (Baudrate is
9600bps) The format of the data string sent is same as the Speed mode.
