ECI Multi Functional Weighing Controller Operating Manual
Page 73
Remote Display(In Batching Program)
It is the section that contains the remote display out (opto-coupler) settings. This menu is an ordered
type menu. Sub-menus are Mode and Baudrate.
Mode
The options are;
1) Inactive: No data transfer can be made to the
remote display.
2) Silo: The value of the silo filled is sent to the
remote display.
3) Total: Total batching value is sent to the
remote display.
4) Weight: Gross weight value is sent to the remote display.
Baudrate
It is the selection for remote display
communication speed. The options are;
1) 1200
2) 2400
3) 4800
4) 9600
Not: The Baudrate menu is not displayed when "Inactivate" mode is selected
