ECI Multi Functional Weighing Controller Operating Manual
Page 150
8.3 Coefficient Calibration
1) It is entered to menu 2.5 for the coefficient calibration.
2) Load cell type is selected. The options are;
1) Esit(2 mV/V)
2) 2.5mV/V
3) 5.0mV/V
4) 10.0mV/V
5) 20.0mV/V
6) 160.0mV/V
3) For entering to Calibration Type menu key is pressed.
4) Coefficient Calibration is selected as the Calibration
Type.
The options are;
1) Load Calibration
2) mV/V Calibration
3) Coefficient Calibration
4) Zero Calibration
5) To proceed press Key.
