ECI Multi Functional Weighing Controller Operating Manual
Page 172
10.3 Slot5 (Optional Input/Output Menu)
E-MDL-RY or E-MDL-DAC modules can be connected to Slot5. Module explanations are as shown in Slot4.
10.4 Slot6 (Optional Expansion Slot)
E-MDL-EXP or E-MDL-BCD modules can be connected to Slot6. The connections are given below in detail.
10.4.1 E-MDL-BCD (Binary Output Module)
This is a BCD or Binary output (19 + 1 Bit) module.
The outputs are active when the pin no 11 (VCC_INN) and pin no 24 (OUT_EN) are short circuited. If the user
wants to receive data continuously, the pins 11,24 are short circuited. No data transfer occurs as long as the
pin no 11 is empty.
-0 (minus zero) value is sent from Binary and BCD outputs before the measurement and in cases of errors.
