ECI Multi Functional Weighing Controller Operating Manual
Page 205
11.6 Batching Program Application
In order to perform batching following module options must be inserted;
11.6.1 Up to 4 Silos
E-MDL-RLY module must be inserted in Slot 4. Other than this, the presence of E-MDL-RLY in Slot 5 or
E-MDL-EXP+EsRelay in Slot 6 is sufficient. If there is E-MDL-RLY module in Slot 5 and E-MDL-EXP+EsRelay
module in Slot 6, the E-MDL-EXP+EsRelay module in Slot 6 is used for Batching.
11.6.2 Up to 16 Silos
E-MDL-RLY module must be inserted in Slot 4.
E-MDL-EXP+EsRelay module must be inserted in Slot 6
11.6.3 Batching Connections
When the batching program is selected, the settings of the Relay modules in Slot 4 and Slot5 and the EXP Module in
Slot 6 cannot be changed and related menus will be locked. The connections of these modules must be made as
follows.
