ECI Multi Functional Weighing Controller Operating Manual
Page 116
7.3.4 Optional In/Out Menu
The menus related to the In/Out module inserted to slot 4 of the device are displayed under this menu. If
there is not any In/Out module, this menu is displayed under the name "Empty Slot".
7.3.4.1 Optional Relay Menu
Following menus will appear if Relay module is inserted to slot 4.
Relay Module
This is the menu where the parameters of the Relay
module are set forth.
Outs
It is the menu where the relay settings are made.
Relay1
It is the menu where the Relay1 settings are made. Following expressions are valid when "Norm.On"
is selected as the "Contact type".
