14.3 Modbus Commands
3
Multiple Record Reading
6
Single Entry Writing
16
Multiple Entry Writing
14.4 Modbus Directly Accessible Memory Map
Case A (16 Bit, LSB to MSB)
BIT(s)
Function
0-3 (/O)
Program Mode: 0: Indicator, 1: Batching, 2: Filling, 3: PLC, 4-15:Out of use
4-8 (/O) (5bits)
Out of use
9 (/O)
1:No load cell module inserted or it is not working, 0:load cell module is working.
10 (/O)
1:ADC input voltage over detected. It must be cleaned by the user.
11 (/O)
Out of use
12 (/O)
1:ADC input voltage is very high. It is 0 when the value returns to normal.
13(Y/O)
Abnormal system operation flag. Set as 1 when wrong operation occurs. It means that the
system has been restarted due to the electricity problems.
14-15 (2bits)
Out of use
