8.2 mV/V Calibration
It is the calibration operation made by using the load cell values without any loading. Following operations are
carried out in order.
1) It is entered to menu 2.5 for the mV/V calibration.
2) Load cell type is selected. The options are;
1) Esit(2 mV/V)
2) 2.5mV/V
3) 5.0mV/V
4) 10.0mV/V
5) 20.0mV/V
6) 160.0mV/V
3) For entering to Calibration Type menu key is pressed.
