ECI Multi Functional Weighing Controller Operating Manual
Page 93
UpperZoneLimit:
It is activated when the measuring type is selected
as "Multi Interval" or "Multi Partition". It is the
maximum value that relates to the 2. scale interval
(e2).
LowerZoneLimit:
It is activated when the measuring type is selected
as "Multi Interval" or "Multi Partition". It is the
maximum value that relates to the 1. scale interval
(e1).
