ECI Multi Functional Weighing Controller Operating Manual
Page 247
12.7.2 Filling Connections
Note: When the filling program is selected, the settings of the Relay modules in Slot 4 and Slot5 and the EXP Module
in Slot 6 cannot be changed and related menus , other than the service menus will be locked. The connections of
these modules must be made as follows.
12.7.2.1 Input Connections
Slot4 E-MDL-RLY Module Input Connections
Slot5 E-MDL-RLY Module Input Connections
