ECI Multi Functional Weighing Controller Operating Manual
Page 220
12.2.2 Scale Filling:
The operation sequence for scale filling is as follows.
1) Start command is waited.
2) Start-up Delay period is waited (if "Start-upDelay" period is entered)
3) Taring is made. (If Auto Taring is selected "On")
4) Quick Filling Output and Weighing in Progress output is activated.
5) The Quick Filling Output becomes passive depending on the quantity taken
6) Slow Filling Output is activated.(If the feeding is selected as "Quick+Slow")
7) Slow Filling Output and Weighing in Progress output is deactivated depending on the quantity taken.
8) Ready Signal is waited.
9) Discharge Delay period is waited (if "DischargeDelay" period is entered)
10) Discharge Output is activated.
11) When it reduced under the Zero Stripe, Operation Completed output is activated and the discharge output
is deactivated.
12) Bag Handling Output is deactivated at the end of the "BagHandWait" period (If it is activated)*
Note:*Bag Handling Output is activated when Bag handling input is detected in any time
Bag handling input is passive for 1 sec after the moment of releasing the bag
